Mullion and transom walls
Aluprof MB-SR50N EFEKT
Description
Aluminium façades and curtain walls
Details
Contact us for detailed technical specifications of this system.
Excellent soundproofing
Resistant and airtight
Aluprof MB-SR50N EFEKT
- Designed for suspended and infill lightweight curtain walls, large glazed surfaces and spatial structures, such as skylights and rotundas.
- The system is based on the MB-SR 50 mullion and transom system
- The structure is similar in appearance to a structural wall
- High aesthetic qualities – the effect of a homogeneous glass plane (small distance between the panes – 20 mm)
- Profile width – 50 mm
- Thermal insulation – group 1 according to DIN 4108
- Glazing – insulating glass with a thickness of 28 to 36 mm
- Glass is fixed with mechanical fasteners
- Optional use of modules with single glazing and insulation
- A large selection of mullions and transoms available in the system ensures optimum use of aluminium
- A wide range of sections and accessories for symmetrical, asymmetrical and angled connections
- Filling the gaps between the glass panes with an insulating cord and special weatherproof silicone gives full resistance to water and air infiltration and excellent thermal insulation
Types of ornamental glass
Silvit
Master point
Master carre
Kura
Matte Delta
Colourless Flutes
Crepi
Spacers
Technical information
