Mullion and transom walls
Aliplast MC-WALL
Description
Modern architectural systems
Details
Contact us for detailed technical specifications of this system.
Excellent soundproofing
Resistant and airtight
Aliplast MC-WALL
- A broad range of mullions and transoms available to meet various static requirements.
- A wide selection of cover strips allows for a range of visual effects on the curtain wall.
- The visual width between mullion and transom is 55 mm.
- Thermal insulation – the heat transfer coefficient for the profiles is U= 1.616-2.815 W/m2K, falling under material group 2.1 according to DIN 4108.
- Thermal break – this is achieved using polyamide reinforced with multidirectionally oriented glass fibre.
- The mullion-to-transom connection has a very high load-bearing capacity, effective in both the wind pressure plane and the glazing load plane, thanks to the use of 2 or 3 ø6 stainless steel connectors per node.
- Traditional transom brackets are utilized and secured solely with front screws.
- At the profile production stage, the transoms are insulated by a thermal break clamped at Aliplast, which prevents potential errors during the subsequent installation of the thermal break.
- Incorporating a transom with an integrated thermal break further accelerates the installation process of the façade wall. The choice of thermal break depends on the infill thickness within the curtain wall.
Types of ornamental glass
Silvit
Master point
Master carre
Kura
Matte Delta
Colourless Flutes
Crepi
Spacers
Technical information
